Product Code
CBLF4.0/4CODGY
Std Pack Size
1
Description
Flexible Cable, Ordinary Duty, 3 Core & Earth, 4 sq-mm, Stranded Copper, 250/440 Volt, 0.31 mm Strands, 12.3 mm Overall Diameter, Conductor Resistance: DC - 4.95 Ohm/km AC - 6.02 Ohm/km, Insulation Resistance: 11 MOhm/km, V-90 PVC Insulation, PVC Sheath, Brown Light Blue White Green/Yellow Cores, Grey Sheath, AS/NZS 3191, AS/NZS 60227
Infosheets
Flexible Cable, Ordinary Duty, 3 Core & Earth, 4 sq-mm, Stranded Copper, 250/440 Volt, 0.31 mm Strands, 12.3 mm Overall Diameter, Conductor Resistance: DC - 4.95 Ohm/km AC - 6.02 Ohm/km, Insulation Resistance: 11 MOhm/km, V-90 PVC Insulation, PVC Sheath, Brown Light Blue White Green/Yellow Cores, Grey Sheath, AS/NZS 3191, AS/NZS 60227
Additional Information
| Brand | Generic |
|---|---|
| Range Name | Powerlex |
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | GAHR06A1004GYAA |
| Conductor Resistance | DC: 4.95 Ohm/km AC: 6.02 Ohm/km |
| Sheath Colour | Grey |
| Core Colours | Brown Light Blue White Green/Yellow |
| Conductor Type | Stranded Copper |
| Conductor Size | 4sq-mm |
| Insulation Resistance | 11 MOhm/km |
| Sheath Material | PVC |
| Insulation Material | V-90 PVC |
| Overall Diameter | 12.3 mm |
| Product Type | Flexible Cable 3 Core |
| Number of Cores | 3 + Earth |
| Voltage | 250/440 Volt |
| Standards | AS/NZS 3191 AS/NZS 60227 |
| Stranding | 0.31 mm |
